Mold Design Process
Step 1: Model or Import the Product
Start by creating or importing the 3D model of the product you want to mold.
Step 2: Create an Assembly with the Product
Use the product model to generate a new assembly file.
Step 3: Insert a New Part (Mold Block)
Insert the mold block (new part) into the assembly.
Step 4: Apply the Cavity Command
Use the cavity feature to “hollow out” the product shape from the mold block.
Step 5: Add Injection Gate and Venting Channels
- Injection Gate Position: Place at the highest point of the product or the geometric center’s highest point.
- Injection Gate Hole Spec: Ø10.3 mm, depth 5 mm
- Runner Hole Spec: Ø6–8 mm, depth 5 mm
- Venting Channel Position: Farthest point from injection gate, or raised features inside mold cavity
- Venting Channel Spec: 0.4 mm wide × 0.2 mm deep
Step 6: Split the Mold (Choose a Suitable Parting Line)
- Select the direction with the largest projected area as the mold opening direction.
- Use the center of the thickness direction as the parting surface for mold splitting.
Note: Since Saltgator mainly injects soft-gel materials, undercuts or draft differences less than 2 mm can generally be ignored without affecting demolding.
